DMM,TRMS AC/DC CAP(DM-810A) Greenlee
True RMS for no-compromise accuracy
Measures voltage, current,resistance, capacitance and frequency
Tests continuity and diodes
Backlit LCD with dual 10,000 count displays
BeepJack warns when test leads are incorrectly inserted in current measurement terminals
Automatic and manual range selection
Relative offset mode to see changes in measurements
Data hold
Use optional USB interface DMSC-9U for direct-To-PC logging
Lifetime limited warranty
Accessories included: (1)9V battery, bead temperature probe (DM-820A, DM-830A only, 400°F/204°C max), test leads, protective boot, carrying case
In stock
- SKU
- S-GLT-DM810A
TTD 1,399.00
Description / DMM,TRMS AC/DC CAP(DM-810A) Greenlee
| Amperage Measurement | 600, 6000μA; 60, 600mA; 6, 10A |
| Battery | (1) 9 V |
| Capacitance | 60, 600nF; 6, 60, 600μF; 6, 25 mF |
| Conductance | 99.99 nS |
| Display | Backlit LCD With Dual 10,000 Count |
| Frequency Measurement | 15Hz- 50kHz Sine Wave, 5Hz - 1MHz Logic Level Square Wave |
| Includes | (1) 9V Battery, Bead Temperature Probe (DM-820A, DM-830A Only, 400°F/204°C Max), Test Leads, Protective Boot, Carrying Case |
| Measurement Category | CAT IV, 1000 V |
| Replacement Part | TC-20 Carrying Case, TSG-3 Sure-Grip Test Leads, TPB Bead Temperature Probe (Included With DM-820A, DM-830A) |
| Resistance Measurement | 600Ω; 6, 60, 600 kΩ; 6, 60 MΩ |
| Standard | CAT IV, C/UL US Listed, TRUE RMS, CE Listed |
| Temperature Rating | K Type, -58 To 1832°F (-50 To 1000°C) |
| Type | Digital |
| Voltage Measurement | 60, 600 mV, 9.999, 99.99, 999.9 V |
